fig# |
type |
psymbol |
dE[eV/at] |
dH[eV/at] |
drb |
dri |
nat |
nn_spec |
ch_spec |
stab |
encut |
ext |
| info | - | Cu | cF4 | STABLE | 0.0000 | - | - | 4 | 4 | Al | LT | m240 | - |
| info | - | Mn | cI58 | STABLE | -0.0000 | - | 0.03 | 29 | 29 | Mn | LT | m270 | - |
| info | - | Mg | hP2 | 0.03168 | 0.0317 | - | - | 2 | 2 | Al | ? | m240 | - |
| info | - | Mn | cP20 | 0.048934 | 0.0489 | - | 0.06 | 20 | 20 | Mn | HT | m270 | - |
| info | - | Cu | cF4 | 0.070807 | 0.0708 | - | - | 4 | 4 | Mn | HT | m270 | - |
| info | - | W | cI2 | 0.09508 | 0.0951 | - | - | 2 | 2 | Al | ? | m240 | - |
| info | - | W | cI2 | 0.148553 | 0.1486 | - | - | 2 | 2 | Mn | HT | m270 | - |
| info | - | W | cI2 | 0.148589 | 0.1486 | - | - | 2 | 2 | Mn | ? | m270 | AF |
| info | - | ClCs | cP2 | ? | -0.2132 | - | - | 2 | 1:1 | Al:Mn | HT | m270 | - |
| info | - | Al3Mn | oP156 | ? | -0.1980 | 0.11 | 0.17 | 156 | 115:41 | Al:Mn | MS | m270 | 41Mn-v1 |
| info | - | Si2Ti | oF24 | ? | -0.2212 | - | 0.05 | 6 | 4:2 | Al:Mn | ? | m270 | - |
| info | - | alpha-AlMn | cP138 | ? | -0.1905 | - | 0.16 | 138 | 114:24 | Al:Mn | ? | m270 | - |
| info | - | Al3Mn | oP156 | ? | -0.1989 | 0.11 | 0.15 | 156 | 115:41 | Al:Mn | ? | m270 | 41Mn-v2 |
| info | - | Mn | cP20 | ? | -0.1235 | 0.05 | 0.06 | 20 | 5:15 | Al:Mn | ? | m270 | - |
| info | - | Al3Mn | oP156 | ? | -0.2052 | 0.12 | 0.15 | 156 | 117:39 | Al:Mn | ? | m270 | 39Mn |
| info | - | Al11Mn4 | aP15 | ? | -0.2775 | - | 0.07 | 15 | 11:4 | Al:Mn | LT | m270 | - |
| info | - | Al12W | cI26 | ? | -0.1087 | - | 0.04 | 13 | 12:1 | Al:Mn | LT | m270 | - |
| info | - | Mn | cP20 | ? | -0.1687 | 0.08 | 0.10 | 20 | 6:14 | Al:Mn | HT | m270 | - |
| info | - | Al6Mn | oC28 | ? | -0.1813 | - | 0.01 | 14 | 12:2 | Al:Mn | LT | m270 | - |
| info | - | Al3Mn | oP156 | ? | -0.2026 | 0.13 | 0.18 | 156 | 116:40 | Al:Mn | ? | m270 | 40Mn |
| info | - | Mg | hP2 | ? | -0.1628 | - | - | 2 | 1:1 | Al:Mn | HT | m270 | - |
| info | - | AuCu | tP4 | ? | -0.2549 | - | - | 4 | 2:2 | Al:Mn | MS | m270 | - |
| info | - | Al10Mn3 | hP26 | ? | -0.2424 | - | 0.03 | 26 | 20:6 | Al:Mn | MS | m270 | - |
| info | - | Al4Mn | hP574 | ? | -0.2073 | 0.11 | 0.12 | 568 | 458:110 | Al:Mn | ? | m270 | - |
| info | - | HgMn | tP2 | ? | -0.2164 | - | - | 2 | 1:1 | Al:Mn | MS | m270 | - |
 |
